Server specifications

Components

Figure 1 Server components
Item
(1) Chassis access panel
(2) Memory
(3) System battery
(4) Chassis open-alarm module
(5) System board
(6) Encryption module
(7) Supercapacitor holder
(8) Supercapacitor
(9) SATA M.2 SSD expander
module
(10) SATA M.2 SSD
Description
N/A
Stores computing data and data exchanged with external storage
temporarily.
Supplies power to the system clock to ensure system time correctness.
Detects if the access panel is removed. The detection result can be
displayed from the HDM Web interface.
One of the most important parts of a server, on which multiple
components are installed, such as processor, memory, and fan. It is
integrated with basic server components, including the BIOS chip and
PCIe connectors.
Provides encryption services for the server to enhance data security.
Secures a supercapacitor in the chassis.
Supplies power to the flash card on the powerfail safeguard module,
which enables the storage controller to back up data to the flash card for
protection when power outage occurs.
Provides M.2 SSD slots.
Provides data storage space for the server.
