Designator Quantity Description
Y1 1
C37 0
C62, C63, C64 0
C104 0
J19, J20 0
R6, R12, R20, R53, 0
R54, R55, R56, R57
R10 0
R19, R21, R41 0
R58 0
R61, R63, R66, R68, 0
R74
R80, R82 0
SNVU851 – NOVEMBER 2023
Submit Document Feedback
Table 6-1. Bill of Materials (continued)
Crystal, 25 MHz, 20 ppm, AEC-Q200 Grade 1,
SMD
CAP, CERM, 10 uF, 10 V, +/- 10%, X7R, 0805 GCM21BR71A106KE22L
Chip Multilayer Ceramic Capacitors for
Automotive
CAP, CERM, 1000 pF, 50 V, +/- 10%, X7R,
0603
Receptacle, 2.5 mm, 3x2, Gold, SMT
RES, 0, 5%, 0.063 W, AEC-Q200 Grade 0,
0402
RES, 20.0 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
RES, 100 k, 1%, 0.1 W, 0603
RES, 4.7 k, 5%, 0.1 W, AEC-Q200 Grade 0,
0603
RES, 10 k, 5%, 0.063 W, AEC-Q200 Grade 0,
0402
RES, 1.00 k, 1%, 0.1 W, 0603
