- Page 1 Using the LP8862-Q1EVM Evaluation Module User's Guide Literature Number: SNVU478A July 2015 – Revised October 2015...
-
Page 2: Table Of Contents
......................Fault Indicator ....................Evaluation Board Schematic ........................Bill of Materials ....................... Appendix A LED Load Board .......................... Revision History Table of Contents SNVU478A – July 2015 – Revised October 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... - Page 3 LED Load Board - Schematic Diagram ................. Forward Voltage for Cree Xlamp ML-B LEDs List of Tables ..................Bill of Materials for LED Load Board SNVU478A – July 2015 – Revised October 2015 List of Figures Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated...
-
Page 4: Read This First
The Texas Instruments LP8862-Q1EVM evaluation module (EVM) helps designers to evaluate the operation and performance of the LP8862-Q1 device. The LP8862-Q1EVM uses the LP8862-Q1 to drive up to 2 LED strings for LCD backlighting with high efficiency. Information about output voltage and current ratings of the LP8862-Q1 can also be found in the device data sheet (SNVSA75). -
Page 5: Description Of The Lp8862-Q1
– Open and Shorted LED Fault Detection – Thermal Shutdown • Minimum Number of External Components Applications • Automotive Infotainment, Instrument Cluster and Backlighting Systems SNVU478A – July 2015 – Revised October 2015 LP8862-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 6: Hardware Setup
POINTS CONNECTOR INPUT VOLTAGE OUTPUT CONFIGURATION CONTROL POINTS SHUNTS FAULT LED CONTROL POINTS Figure 1. Evaluation Board Connectors and Setup LP8862-Q1EVM Evaluation Module SNVU478A – July 2015 – Revised October 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 7: Board Layout
Figure 4. Evaluation Board Stackup • 4-layer board FR4 • Material thickness 1.616 ± 10% mm • Surface finish immersion gold SNVU478A – July 2015 – Revised October 2015 LP8862-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 8: Start-Up Of The Evm And Power Sequences
The backlight is shut down (LEDs turned off) by setting PWM input low or when VDDIO/EN = 0. If VDDIO/EN is set low, the LP8862-Q1 enters low-power mode with internal LDO disabled. LP8862-Q1EVM Evaluation Module SNVU478A – July 2015 – Revised October 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 9: Boost Converter
Frequency should be higher than the switching frequency set by R resistor and be in range FSET 1.2...1.5 × ƒ SW SET SNVU478A – July 2015 – Revised October 2015 LP8862-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 10: Voltage Control
• = 1.2 V • – current setting resistor (R4), kΩ ISET • – output current per output, mA LP8862-Q1EVM Evaluation Module SNVU478A – July 2015 – Revised October 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 11: Brightness Control
An open-drain FAULT pin indicates faults. The FAULT pin can be connected to LED D2 for indication (jumper J10). SNVU478A – July 2015 – Revised October 2015 LP8862-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 12: Evaluation Board Schematic
Evaluation Board Schematic www.ti.com Evaluation Board Schematic Figure 9. Evaluation Board Schematic LP8862-Q1EVM Evaluation Module SNVU478A – July 2015 – Revised October 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 13: Bill Of Materials
Bill of Materials www.ti.com Bill of Materials The following is the bill of materials for the LP8862-Q1EVM: DESIGNATOR DESCRIPTION MANUFACTURER PART NUMBER C1, C4, C6, C7 CAP, CERM, 10uF, 50V, +/-10%, X5R, CGA5L3X5R1H106K160AB 1206_190 C2, C8 CAP, AL, 33uF, 50V, +/-20%, 40 mohm,... -
Page 14: Appendix A Led Load Board
NOTE: The LED board is not included with the EVM -- contact your local TI sales representative if board is needed. Figure 10. LED Load Board - Top Side Figure 11. LED Load Board - Bottom View LED Load Board SNVU478A – July 2015 – Revised October 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... - Page 15 D100 D120 J105 J126 J106 J127 10.0 10.0 10.0 10.0 10.0 10.0 Figure 12. LED Load Board - Schematic Diagram SNVU478A – July 2015 – Revised October 2015 LED Load Board Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated...
-
Page 16: Bill Of Materials For Led Load Board
Samtec TSW-107-07-G-S D1...D120 Cool White SMD LED XLamp mL-B Cree MLBAWT-A1-0000-000W51 Figure 13. Forward Voltage for Cree Xlamp ML-B LEDs LED Load Board SNVU478A – July 2015 – Revised October 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 17: Revision History
Changed Product Preview to Production Data status NOTE: Page numbers for previous revisions may differ from page numbers in the current version. SNVU478A – July 2015 – Revised October 2015 Revision History Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... - Page 18 STANDARD TERMS AND CONDITIONS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, or documentation (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms and conditions set forth herein. Acceptance of the EVM is expressly subject to the following terms and conditions.
