03 CONTROLS & FUNCTIONS
LVM-180A FRONT
• [INPUT SIGNAL INDICATOR] Lamp
- Used to display the current input mode.
CVBS: Composite, DVI-A: DVI Analog
DVI-D: DVI Digital, HDMI: HDMI
SDI: SDI-A / B
• [ANALOG] Button/Lamp
- Used to select desired Analog input.
- Press the button to activate the analog input
menuselection, then use the Knob to select the
desired input.
*Please refer to "7. Button Functions [1] ANALOG
Button" for more information.
• [DIGITAL] Button/Lamp
- Used to select desired Digital input. (HDMI, DVI
Digital)
- Press the Digital Button to activate the Digital
input menuselection, then use the Knob to
select desired input.
*Please refer to "7. Button Functions [2] DIGITAL"
for more information.
• [SDI-A], [SDI-B] Button/Lamp
- Used to select SDI-A and SDI-B input.
• [F1 ~ F5] Button/Lamp
- Performs the function that the user sets as
hot-keys.
- The selectable hot-key menu list comes up
when you hold the key for 2 seconds. You can
select the hot-key functions from it.
• [SCAN] Button/Lamp
- Used to change the scan mode.
*Please refer to "8. Other Functions [1] SCAN" for
more information.
• [ASPECT] Button/Lamp
- Used to change the display ratio between 4:3
and 16:9.
- Activates in the order of [4:3]-[2.35:1]-[1.85:1]-
[15:9]-[16:10]-[AUTO]-[16:9].
• [MARKER] Button/Lamp
- Used to activate/deactivate the Marker.
- The Marker is normally displayed when you
select Aspect ratio you want in OSD Menu.
8
• [H/V DELAY] Button/Lamp
- Used to check horizontal sync and vertical sync
simultaneously.
• [BLUE ONLY/MONO] Button/Lamp
- Press the button to remove red and green from
the input signal and display the screen only
under a blue signal.
Press the button again to activate mono mode.
- This function is not activated in the RGB, DVI
ANALOG, DVI DIGITAL, HDMI modes.
• [INFO.] Button
- Displays the current function and setting of the
monitor.
• [MENU/EXIT] Button/Lamp
- Activates OSD menu.
• [ENTER/UP/DOWN] Knob
- Used to confirm a chosen value.
- Used to move the cursor in OSD menu.
• [POWER] Button/Lamp
- Turns on or off the monitor power.
• [OPERATE] Lamp
- Indicates the status of power connection and
monitor operation.
- The LED is off when the power is off.
- The LED is red when the monitor is in the
waiting mode with power on.
- The LED is green when the monitor is operating.
• [AUDIO OUT] (Phone jack)
- Outputs dis-embedded audio signal, HDMI
audio signal or stereo signal from outside
through internal speaker or phone jack.
• [USB]
- Updates new firmware and color calibration.
• [TALLY] Lamp
- Tally lamp that can be toggled in green or red
using the REMOTE(RJ-45) port.
