Center of Gravity

Measure aft of the LE at the wing root of fuse10.7", place a piece of 1/2" wide tape on
the fuselage.
Control Surface Deflections
Control
Stab (measured at the stab split.)
Aileron (measured at the tip)
Flaps (per flap gauge)
Rudder (measured at the top)
Connecting RX wires
The wires are labeled from the factory. Follow the chart below to connect the servos.
DX18 Connection Chart
RX Port (1)Throttle
Surface Throttle
RX Port (7)Aux2
Surface Right Flap
DX18 and DX18QQ Transmitter File
The BVM Demo models are setup on Spektrum DX18 transmitters.
Important!!! Check the directions of all flight controls before each flight.
Switch/Lever/Trimmer Channel
Switch A
Switch D (Flight Modes)
Switch E
L. Trim
Switch F
Switch G
Switch A
BVM ® 2023
KingCat-V2
Assembly & Operation Manual
High Rate Travels
Up 2-3/8
Up 1-1/16
Take Off
Inboard 1"
(2)Aileron (3)Elevator
Right Ail Right Elev
(8)Aux3 (9)Aux4
Gear Left Elev
(8)Aux 3 Gear
Flaps
Brakes
Steering Trim/(11)Aux 6
Aileron Rates
Gyro
Timer
35
Down 2-3/8"
Down 7/8"
Landing
Outboard 1.5"
(4)Rudder (5)Gear
Rudder Left Flap
(10)Aux5 (11)Aux6
Brake Nose Steering
Output
Landing Gear, Down is Down
Up is Normal flight
Mid Take Off
Down is Landing
Pos 0-off, Pos 1-pulse, Pos 2-stop
Down for Right Steering Trim
Up for Left Steering Trim
Up (0) is High
Pos 0- off, Pos 1- low, Pos 2- high
(6)Aux1
Left Ail
(12)Aux7
Gyro
