SMC Networks AWM20-01 Series Operation Manual page 18

Option symbol
Semi-standard symbol
Appearance
and part No.
Option symbol
Semi-standard symbol
Semi-standard: －
Piping port
thread ty pe
Rc
G
NPT
Appearance
Semi-standard: 6
and part No.
Piping port
thread ty pe
Rc
G
NPT
Option symbol
Semi-standard symbol
Semi-standard: 8
Piping port
thread ty pe
Rc
G
NPT
Appearance
and part No.
－
8
Note 1)
C
－
(9) Part No.
AD37-D
AD37N(-Z)-D
(9) Part No.
AD37-6-D
AD37N-6(Z)-D
Note 1)
C
8
(9) Part No.
AD37-8-A
AD37N-8(Z)-A
Semi-standard: 8J
Piping port
thread ty pe
Rc
G
NPT
6
Semi-standard: 2
Piping port
thread ty pe
Rc
G
NPT
Note 1) Minimum operating pressure is 0.15 MPa.
Note 2) Part No. (9) includes Bowl seal (8). Refer to
section [12. Disassembly Drawing] (P38).
Note 3) "Z" in Part No. (9) indicates semi-standard
specifications. The pressure unit: psi.
The temperature unit:
Note 4) Refer to section [4. How to Order] (P10) for
option and semi-standard symbols.
-17-
－
8J
(9) Part No.
C3LF-8J-A
C3LFF-8J-A
C3LFN-8J(Z)-A
Note 1)
C
2
(9) Part No.
AD37-2-A
AD37N-2(Z)-A
o
F.
