1313DXT-I/1515DXT-I/2520DX-I/3030DX-I X-ray Detectors
Table 24 Diagnostic Data (Continued)
Pixel Column Register Name
9 Detector Type
Firmware Revision
10
and Build
11 Frame Info
12 Frame Count
Board Serial Num-
13
ber LSW
Board Serial Num-
14
ber Middle Word
Board Serial Num-
15
ber MSW
Detector Temp
16
Sensor 1
Detector Temp
17
Sensor 2
Detector Temp
18
Sensor 3
Detector Temp
19
Sensor 4
Detector Temp
20
Sensor 5
Detector Temp
21
Sensor 6
Detector Temp
22
Sensor 7
Detector Temp
23
Sensor 8
24 Voltage 1
25 Voltage 2
26 Voltage 3
27 Voltage 4
16-bit Data
1313DX=40
1515DX=41
2520DX=42
2530C=43
Bit 15~8=Revision
Bit7~0=Build
Bit 7 =Frame Valid
16 bit frame counter
NU
NU
NU
NU
2010 - 2070
2020 - 2080
2040 - 2100
1710 - 1810
www.vareximaging.com
Formula
V=0.00162*(ADC)
V=0.002442*(ADC)
V=0.005818*(ADC)
V=0.004908*(ADC)
Note
User_Sync
Blanking
Continuous
Counter
3.3VA
5VA
M12VA
AVGL
