8.3.2

Connecting the Cables

To connect the cables, perform the following steps.
of how a typical system setup appears.
Connect the Mains to the Power Supply.
1
Connect the Power Supply to the Detector Cable.
2
Connect Receptor Sync to Generator to the generator interface.
3
Connect the Detector Cable to the Power connector on the detector.
4
Connect the Ethernet cable between a Gigabit capable port on the host computer and the
5
detector. The use of a Hub or switch is neither recommended or supported.
Connect the Ground Cable to the grounding lug (not shown in
6
Connect the Ground Cable to an acceptable ground connection.
7
Connect the Mains Cable to an available power outlet.
8
WARNING
The X-ray generator interface is user-supplied equipment.
Note
10
Replacement power supply cords may use inadequately-rated wiring
and could damage the detector. If a replacement power supply cord is
required, please request one directly from Varex Imaging to ensure
that the power cord meets the standards for the detector.
www.vareximaging.com
1313DXT-I/1515DXT-I/2520DX-I/3030DX-I X-ray Detectors
Figure 4 provides a graphical representation
Figure 4).
