1313DXT-I/1515DXT-I/2520DX-I/3030DX-I X-ray Detectors

Figure 12 User_Sync Blanking De-Activated

All frames are readout 2ms after the rising edge of User_Sync. See
Figure
12.
Note
www.vareximaging.com
19
