Table 3 Standards and Regulations
Standard
IEC 61010-1:2010
UL 61010-1
CAN/CSA 22.2
CE Mark
Note: The detectors do not contain any applied parts.
Note: A Declaration of Conformity has been filed for this product and available upon request by
contacting Varex Imaging Corporation.
8.0

Description of the Detectors

The detectors described in this user manual incorporate Gigabit Ethernet data communication,
operate at lower power levels, and with improved cycle time. These detectors are specifically
designed to meet the needs of industrial applications utilizing multiple sensitivity ranges. They
acquire images at usual video frame rates over a wide range of dose.
Raw data is normalized for offset and gain variations pixel-by-pixel by the Virtual Command
Processor (VCP) software that comes with the detector. The VCP performs all the interface
functions with the detector such as control, image acquisition and calibration. The VCP also
interpolates the value of any pixels identified as defective. A single-output power supply
provides all the power required for the detector.
VCP software controls the detector operation through Ethernet. System integrators receive a
library of functions for image acquisition and calibration.
Figure 1 displays a customer system showing the configuration of a detector in the context of the
overall imaging system.
4
Part 1 General Requirements (3rd Ed.)
Part 1 General Requirements (3rd Ed.)
61010-1-12 (3rd Ed.)
Varex Imaging products are designed and manufactured to meet the Low
Voltage Directive 2014/35/EU
www.vareximaging.com
1313DXT-I/1515DXT-I/2520DX-I/3030DX-I X-ray Detectors
Description
