1313DXT-I/1515DXT-I/2520DX-I/3030DX-I X-ray Detectors
Table 14
Detector Cable 9-Pin D-Sub Pinout for 1313DXT-I/1515DXT-I and 2520DX-I
Connector Pin
1
2
3
4
5
6
7
8
9
Table 15
Detector Cable 9-Pin D-Sub Pinout for 3030DX-I
Connector Pin
1
2
3
4
5
6
7
8
9
Table 16
Lemo EXG.1B.308.HLN Pinout 1313DXT-I/1515DXT-I and 2520DX-I
Connector Pin
1
2
3
4
5
www.vareximaging.com
Signal
Exp_OK_Pos
Exp_OK_Neg
User_Sync_Pos
User_Sync_Neg
No Connection
No Connection
No Connection
No Connection
No Connection
Signal
Exp_OK_Neg
Exp_OK_Pos
User_Sync_Pos
User_Sync_Neg
No Connection
No Connection
No Connection
No Connection
No Connection
Signal
+15VDC
+15VDC
GND15V
GND15V
Exp_OK_Neg
21
