10.3

Link to the Detector

Wait 6 seconds after powering on the detector for the FPGA to initialize
Note
before establishing a link to the detector.
Click the ViVA icon.
1
The application launches.
2

Figure 27 The ViVA icon

Click Acquisition from the menu bar, click Receptor Setup.
3

Figure 28 Receptor Setup

A Receptor Selections Window will appear, choose the desired detector to link. Click OK.
4

Figure 29 Receptor Selections Window
