Electrical Rating; External Power; Table 7 External Power Supply Specification (If Supplied With The Unit); Table 8 Electrical Rating (If Power Supply Not Provided With The Unit) - Varex Imaging PaxScan 1313DXT-I Manual

1313DXT-I/1515DXT-I/2520DX-I/3030DX-I X-ray Detectors
8.5

Electrical Rating

Electrical ratings for the detectors.
Table 7 External Power Supply Specification (if supplied with the unit)
Detector
1313DXT-I/1515DXT-I
2520DX-I
3030DX-I
Table 8 Electrical Rating (if power supply not provided with the unit)
Detector
1313DXT-I/1515DXT-I
2520DX-I
3030DX-I
8.5.1

External Power

Table 9 shows the power requirements for two different input voltages. The range of input
voltage is 12VDC to 32VDC.
Table 9 External Power
Detector
1313DXT-I/1515DXT-I
2520DX-I
3030DX-I
XP Power Type Input Voltage
AHM85PS15 100V - 240V
AHM85PS15 100V - 240V
AHM85PS24 100V - 240V
Continuous Power Rating
Supply Voltage
24VDC
15VDC
24VDC
15VDC
24VDC
www.vareximaging.com
Input
Frequency
50Hz - 60Hz
50Hz - 60Hz
50Hz - 60Hz
11 Watts
12 Watts
24 Watts
Power on Surge
2.7A
2.8A
2.8A
2.9A
2.8A
Input
DC Output
Current
1.5A 15V
1.5A 15V
1.0A +24V/3.54A
Input Voltage
12VDC - 32VDC
12VDC - 32VDC
21VDC - 30VDC
Current Power
450mA 10.8 Watts
690mA 10.4 Watts
510mA 12 Watts
810mA 12.2 Watts
1000mA 24 Watts
