COM-HPC Server Base User's Guide

6.8. USB2.0 Ports Header

USB4_5: USB2.0 Port 4 and Port 5 header
USB6_7: USB2.0 Port 6 and Port 7 header
Pin Signal
1 +5V 2
3 U2_USB_R_N 4
5 U2_USB_R_P 6
7 GND 8
9 GND 10

6.9. USB3.x Ports Header

FP_USB: USB Front Panel Header
Pin Signal
1 TP336 2
3 USB2_P_CN 4
5 USB2_N_CN 6
7 GND 8
9 USB_SSTX4_P_CN 10
11 USB_SSTX4_N_CN 12
13 14
GND
15 USB_SSRX4_P_CN 16
17 USB_SSRX4_N_CN 18
19 +5V
Page 28
+5V
U2_USB_R_N
U2_USB_R_P
GND
NC
USB_DS3_DP_CN
USB_DS3_DN_CN
GND
USB_SSTX5_P_CN
USB_SSTX5_N_CN
GND
USB_SSRX5_P_CN
USB_SSRX5_N_CN
USB_VBUS
