Row A
A23 ETH5_RX-
A24 ETH5_RX+
A25 GND
A26 ETH6_RX-
A27 ETH6_RX+
A28 GND
A29 ETH7_RX-
A30 ETH7_RX+
A31 GND
A32 RSVD
A33 RSVD
A34 GND
A35 ETH4_TX-
A36 ETH4_TX+
A37 GND
A38 ETH5_TX-
A39 ETH5_TX+
A40 GND
A41 ETH6_TX-
A42 ETH6_TX+
A43 GND
A44 ETH7_TX-
A45 ETH7_TX+
A46 GND
A47 USB1_AUX-
A48 USB1_AUX+
A49 GND
A50 eSPI_IO0
A51 eSPI_IO1
A52 eSPI_IO2
A53 eSPI_IO3
A54 eSPI_CLK
A55 GND
A56 PCIe_CLKREQ0_LO#
A57 PCIe_CLKREQ0_HI#
A58 GND
A59 PCIe_BMC_TX-
Page 20
Row B
B23 RSVD
B24 VCC_5V_SBY
B25 USB67_OC#
B26 USB45_OC#
B27 USB23_OC#
B28 USB01_OC#
B29 SML1_CLK
B30 SML1_DAT
B31 PMCALERT#
B32 SML0_CLK
B33 SML0_DAT
B34 USB_PD_ALERT#
B35 USB_PD_I2C_CLK
B36 USB_PD_I2C_DAT
B37 USB_RT_ENA
B38 USB1_LSRX
B39 USB1_LSTX
B40 USB0_LSRX
B41 USB0_LSTX
B42 GND
B43 USB0_AUX-
B44 USB0_AUX+
B45 RSVD
B46 RSVD
B47 VCC_BOOT_SPI
B48 BOOT_SPI_CS#
B49 BSEL0
B50 BSEL1
B51 BSEL2
B52 eSPI_ALERT0#
B53 eSPI_ALERT1#
B54 eSPI_CS0#
B55 eSPI_CS1#
B56 eSPI_RST#
B57 GND
B58 PCIe_BMC_RX-
B59 PCIe_BMC_RX+
Copyright © 2023 ADLINK Technology, Inc.
Row C
C23 ETH1_TX-
C24 ETH1_TX+
C25 GND
C26 ETH2_TX-
C27 ETH2_TX+
C28 GND
C29 ETH3_TX-
C30 ETH3_TX+
C31 GND
C32 USB3_SSRX-
C33 USB3_SSRX+
C34 GND
C35 USB2_SSRX-
C36 USB2_SSRX+
C37 GND
C38 USB1_SSRX0-
C39 USB1_SSRX0+
C40 GND
C41 USB1_SSRX1-
C42 USB1_SSRX1+
C43 GND
C44 USB0_SSRX0-
C45 USB0_SSRX0+
C46 GND
C47 USB0_SSRX1-
C48 USB0_SSRX1+
C49 GND
C50 BOOT_SPI_IO0
C51 BOOT_SPI_IO1
C52 BOOT_SPI_IO2
C53 BOOT_SPI_IO3
C54 BOOT_SPI_CLK
C55 GND
C56 PCIe_REFCLK0_HI-
C57 PCIe_REFCLK0_HI+
C58 GND
C59 PCIe_REFCLK0_LO-
PICMG COM-HPC Rev 1.0
Row D
D23 ETH1_RX+
D24 GND
D25 ETH2_RX-
D26 ETH2_RX+
D27 GND
D28 ETH3_RX-
D29 ETH3_RX+
D30 GND
D31 USB3_SSTX-
D32 USB3_SSTX+
D33 GND
D34 USB2_SSTX-
D35 USB2_SSTX+
D36 GND
D37 USB1_SSTX0-
D38 USB1_SSTX0+
D39 GND
D40 USB1_SSTX1-
D41 USB1_SSTX1+
D42 GND
D43 USB0_SSTX0-
D44 USB0_SSTX0+
D45 GND
D46 USB0_SSTX1-
D47 USB0_SSTX1+
D48 GND
D49 SATA0_RX-
D50 SATA0_RX+
D51 GND
D52 SATA0_TX-
D53 SATA0_TX+
D54 GND
D55 SATA1_RX-
D56 SATA1_RX+
D57 GND
D58 SATA1_TX-
D59 SATA1_TX+
