Led Diagnostics - Altronix M Series Installation Manual

Power Supply Board
LED
Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF
Red (Bat) Battery Status
ON Normal operating condition.
OFF Battery fail/low battery.
MOM5 - Output Module
LED
Power (Green)
Trigger (Green)
Outputs (Red)
AL1024ULM Battery Size Calculation Worksheet.
A. AL1024ULM internal current consumption
B. Load current consumption
C. Stand-by time required (hours)
D. Battery capacity required for stand-by
E. AL1024ULM internal power consumption
F. Load current consumption
G. Alarm duration
(Hours, example: 15 Min = 0.25 Hour)
H. Battery capacity required for Alarm
I. Total calculated battery capacity
J. Battery capacity required
Note: AL1024ULM power supply is designed to work with batteries up to 65AH. Please note, line [I] must not
exceeds 36AH. You have to reduce either standby current consumption or standby time in order to comply with
requirement.
To determine actual battery size please round line [J] to the nearest larger standard battery size.
M Series Installation Guide

LED Diagnostics:

Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery is supplying power.
No DC output. Short circuit or thermal overload condition.
No DC output. Loss of AC. Discharged battery.
ON
Normal operating condition.
Input is triggered (alarm condition).
Output tripped due to a short circuit or
overload condition.
––––––––––––––––––––––––––––––––––––––––––––––––––––––
OFF
Power failure.
No input trigger (non-alarm condition).
Normal operation.
(stand-by)
(stand-by)
(A+B)*C
(Alarm)
(Alarm)
(Alarm)
(E+F)*G
D+H
I*1.8 (safety factor)
0.13A
A
H
AH
0.13A
A
H
AH0
AH
AH
- 11 -
