Access Power Controllers with
Power Supplies
Installation Guide
Models Include:
Maximal3FV
- 12VDC @ 4.6A or 24VDC @ 5.2A.
- Sixteen (16) fuse protected outputs.
Maximal5FV
- 12VDC @ 8.6A.
- Sixteen (16) fuse protected outputs.
Maximal7FV
- 24VDC @ 9.2A.
- Sixteen (16) fuse protected outputs.
Rev. SFFV031115
Installing Company: ________________ Service Rep. Name: ______________________________________
Address: ___________________________________________________ Phone #: _____________________
More than just power.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Maximal3FV and is the answer not in the manual?

Questions and answers

Related Manuals for Altronix Maximal3FV

Summary of Contents for Altronix Maximal3FV

  • Page 1 Access Power Controllers with Power Supplies Installation Guide Models Include: Maximal3FV - 12VDC @ 4.6A or 24VDC @ 5.2A. - Sixteen (16) fuse protected outputs. Maximal5FV - 12VDC @ 8.6A. - Sixteen (16) fuse protected outputs. Maximal7FV - 24VDC @ 9.2A.

  • Page 2: Table Of Contents

    Enclosure Dimensions ............pg. 12 - 2 - Maximal3FV / Maximal5FV / Maximal7FV Access Power Controllers (Fused)

  • Page 3: Maximalfv Series Overview

    MaximalFV Series Overview: Altronix MaximalFV Access Power/Controllers distribute and switch power to access control systems and acces- sories. They convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into sixteen (16) indepen- dently controlled 12VDC or 24VDC fuse protected outputs. These Fail-Safe/Fail-Secure power outputs may be converted to dry form “C”...

  • Page 4: Eflow Power Supply/Charger

    There are no user serviceable parts inside. Refer installation and servicing to qualified service personnel. 3. Select desired DC output voltage by setting SW1 to the appropriate position on the Maximal3FV power supply (Fig. 1a, pg. 7). Maximal5FV power supply is factory set at 12VDC and Maximal7FV power supply is factory set at 24VDC.
  • Page 5 When using AC power supplies, polarity needs not to be observed. (Fig. 2d, pg. 8) All field wiring connections must be made employing suitable gauge CM or FPL jacketed wire or equivalent substitute (Fig. 4a, pg. 10). Maximal3FV / Maximal5FV / Maximal7FV Access Power Controllers (Fused) - 5 -...

  • Page 6: Maintenance

    A removed battery is reported within 5 minutes. Battery reconnection is reported within 1 minute (Fig. 3, pg. 9). Stand-by battery connections. + BAT – Maximum charge current 1.54A (Fig. 3, pg. 9). - 6 - Maximal3FV / Maximal5FV / Maximal7FV Access Power Controllers (Fused)

  • Page 7: Access Power Controller Terminal Identification

    INPUT 8 IN, GND (request to exit buttons, exit PIRs, etc.) 12VDC to 24VDC trigger controlled outputs are rated at 2.5A. Maximal3FV - 10.0-13.2VDC @ 4.6A or 20.19-26.4VDC @ 5.2A. Maximal5FV - 10.03-13.2VDC @ 8.6A. OUTPUT 1- Maximal7FV - 20.17-26.4VDC @ 9.2A.

  • Page 8: Access Power Controller Typical Application Diagram (For Each Acm8)

    Door Holders Intact = One P/S Input Intact = DC Input Cut = Dual P/S Input Cut = AC Input J2 J1 NC C NO COM OUTPUT 8 - 8 - Maximal3FV / Maximal5FV / Maximal7FV Access Power Controllers (Fused)

  • Page 9: Maximalfv Battery Hookup And Tamper Switch Installation

    40AH or 65AH batteries. Tamper Switch Enclosure or equivalent Edge of (Not Included) Enclosure Fig. 3b to Access Control Panel or U.L. Listed Reporting Device Maximal3FV / Maximal5FV / Maximal7FV Access Power Controllers (Fused) - 9 -...

  • Page 10: Nec Power-Limited Wiring Requirements

    (non power-limited) Fig. 4a Incorrect Wire Correct Wire Handling Handling External Supervisory Jacketed Connections Shield (power-limited) Wire Insulation Pull back Solid Copper external jacketed Conductors shield approx. 1/2”. - 10 - Maximal3FV / Maximal5FV / Maximal7FV Access Power Controllers (Fused)

  • Page 11: Facp/Optional Power Supply Hook-Up Diagrams

    Fig. 8 Normally Closed: Non-Latching FACP Fig. 9 Normally Closed: Latching FACP trigger trigger input: input with reset: N.C. RESET SWITCH N.C. DRY TRIGGER INPUT N.C. TRIGGER JUMPER JUMPER INPUT Maximal3FV / Maximal5FV / Maximal7FV Access Power Controllers (Fused) - 11 -...

  • Page 12: Enclosure Dimensions

    19” (482.6mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIMaximal3FV/5FV/7FV Series G27R...
