Altronix M Series Installation Manual page 9

Fig. 4 - AL1024ULM
CAUTION: De-energize unit prior to servicing. For continued protection
against risk of electric shock and fire hazard replace fuses with the same type
and rating (see marking on the board). Do not expose to rain or moisture.
Wire Strap
(from
Enclosure
to Door)
Fig. 4a
Battery & AC
Supervision Circuit
(power-limited)
Keep power-limited wiring separate from non power-limited.
Use minimum 0.25" spacing.
CAUTION: Optional rechargeable stand-by batteries must match
the power supply output voltage setting.
M Series Installation Guide
Earth
ground
115VAC
power
mains
non power-
limited
Class 1
DC Outputs
to devices
(power-limited)
Optional Rechargeable
12VDC Stand-by Battery
non power-limited
NEG1 NEG2 NEG3 NEG4 NEG5 - DC INPUT +
1 2 3 4 5
POS (+) DC OUTPUT (ALARM)
TRIGGER
LED
6 7 8 9 10
POS (+) DC OUTPUT(STANDBY) DRY OUTPUT POWER FAIL
Battery
connections
non power-limited
AC DELAY
Fire
Alarm
Inteface
MOM5_S
Power-
limited
POWER
ON
LED
NC C NO NC C NO
Fig. 4b
Optional Rechargeable
12VDC Stand-by Battery
J1
AC Delay
