- Page 1 ACMS12 Series Sub-Assembly Access Power Controllers Models Include: ACMS12 - Twelve (12) Fuse Protected Outputs ACMS12CB - Twelve (12) PTC Protected Outputs Installation Guide More than just power. Rev. 061622...
-
Page 2: Specifications
Overview: Altronix ACMS12/ACMS12CB are sub-assemblies designed to be used in Altronix wall and rack mount enclosures. Dual input design allows power to be steered from two (2) independent low voltage 5 to 24VDC power sources into twelve (12) independently controlled fuse or PTC protected outputs. Outputs are activated by an open collector sink, normally open (NO), normally closed (NC) dry trigger input, or wet output from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc. -
Page 3: Installation Instructions
Installation Instructions: Wiring methods shall be in accordance with the National Electrical Code NFPA 70/NFPA 72/ ANSI / Canadian Electrical Code / CAN/ULC-S524/ULC-S527/ULC-S537, and with all local codes and authorities having jurisdiction. Product is intended for indoor dry use only. Refer to Sub-Assembly Installation Instruction for mounting Rev. - Page 4 Fig. 3 - ACMS12 Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Input 9 Input 10 Input 11 Input 12 COM -- NO–––NC FACP OUTPUT NO–––NC FACP OUTPUT NO–––NC FACP OUTPUT PWR1 + 1 2 3 4 1 2 3 4 1 2 3 4...
-
Page 5: Led Diagnostics
Daisy Chaining Two (2) ACMS12(CB) Dual Output Access Power Controllers: Use 18 AWG or larger UL Listed wire equipped with 1/4” UL Recognized quick connect terminals rated for proper voltage/current for all jumper connections. 1. Connect first ACMS12(CB) board’s spade lug marked [PWR1 +] to the second ACMS12(CB) board’s terminal marked [+ PWR1]. -
Page 6: Typical Application Diagram
Typical Application Diagram: Fig. 6 Access Control Panel Normally Open (N.O.) Door Releasing Device Output (turn corresponding INPUT switch OFF) Relay Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Input 9 Input 10 Input 11 Input 12 COM --... - Page 7 12V (from VR6 regulator) 12VDC 12VDC (from external power supply) 11.7-12VDC 24VDC (from external power supply) 23.7-24VDC Maximum Output of Altronix Power Supplies: UL Listed or Recognized Power Supply Output Voltage Setting Max. Output Current AL400ULXB2 / eFlow4NB 12VDC or 24VDC...
- Page 8 VR6 - Voltage Regulator Overview: VR6 voltage regulator converts a 24VDC input into a regulated 5VDC or 12VDC output. It is specifically designed to work with ACMS12(CB) by allowing to mount the Access Power Controller directly on top of VR6 to save enclosure space and simplify connections.
-
Page 9: Hookup Diagrams
Hook-Up Diagrams: Fig. 8 - Daisy-chaining one or more ACMS12 units. EOL Jumper [EOL JMP] should be installed in the EOL position. Non-Latching. GND GND –F –R GND GND –F –R Jumper Jumper Fig. 9 - Daisy-chaining one or more ACMS12 units. EOL Jumper [EOL JMP] should be installed in the EOL position. - Page 10 Hook-Up Diagrams: Fig. 10 - Polarity reversal input from FACP Fig. 11 - Polarity reversal input from FACP signaling circuit output (polarity is signaling circuit output (polarity is referenced in alarm conditiion). referenced in alarm condition). Non-Latching. Latching. GND GND –F –R GND GND...
- Page 11 Notes: ACMS12/CB Sub-Assembly Installation Guide - 11 -...
- Page 12 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IIACMS12/ACMS12CB F16V - 12 - ACMS12/CB Sub-Assembly Installation Guide...
