ACM8 & ACM8CB Access Power Controller
LED
LED 1- LED 8 (Red)
Trg (Green)
ACM8 & ACM8CB Access Power Controller
Terminal
Legend
- Power +
- Control +
TRIGGER
INPUT 1- INPUT 8
IN, GND
OUTPUT 1-OUTPUT 8
NC, C, NO, COM
FACP INTERFACE
T, + INPUT -
FACP INTERFACE
NC, C, NO

LED Diagnostics:

ON
Output relay(s) energized.
FACP input triggered (alarm condition).
Terminal Identification Tables:
Function/Description
12VDC or 24VDC input from power supply board.
These terminals can be connected to a separate, UL listed power supply to
provide isolated operating power for the ACM8/ACM8E/ACM8CB/ACM8CBE
(jumpers J1and J2 Must be removed).
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit pir's, etc.).
12 to 24 volts AC/DC trigger controlled outputs:
Fail-Safe [NC positive (+) & COM Negative (-)],
Fail-Secure [NO positive (+) & COM Negative (-)],
Auxiliary output [C positive (+) & COM Negative (-)]
(When using AC power supplies polarity need not be observed),
NC, C, NO become form "C" 5 amp 24VAC/VDC rated dry outputs when fuses are
removed (ACM8/ACM8E). Contacts shown in a non-triggered state.
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP output circuit (Fig. 3 through 7, pg. 6).
Form "C" relay contact rated @ 1 amp 28VDC for alarm reporting.
(This output has not been evaluated by UL).
OFF
Output relay(s) de-energized.
FACP normal (non-alarm condition).
- 5 -
