Typical Application Diagrams - Altronix M Series Installation Manual

Fig. 5
MOM5 module shown with wet and/or dry normally
closed trigger inputs (Non-Latching):
Fig. 6 - Two (2) or more MOM5 modules shown with wet and/or dry normally closed trigger inputs (Non-Latching):
– DC INPUT +
TRIGGER NC C NO NC C NO
LED
DRY OUTPUT POWER FAIL
Fig. 7 - Two (2) or more MOM5 modules shown with wet and/or dry normally open trigger inputs (Non-Latching):
– DC INPUT +
TRIGGER NC C NO NC C NO
LED
DRY OUTPUT POWER FAIL
- 12 -

Typical Application Diagrams:

DC VOLTAGE INPUT
FROM FACP SIGNALING
OUTPUT OR ACCESS
CONTROL DEVICE
EOL 2.2K
N.C. INPUT FROM
FACP OR ACCESS
CONTROL DEVICE
DC VOLTAGE INPUT
FROM FACP SIGNALING
OUTPUT OR ACCESS
CONTROL DEVICE
EOL 2.2K
N.C. INPUT FROM
FACP OR ACCESS
CONTROL DEVICE
POWER ON
LED
DC VOLTAGE INPUT
FROM FACP SIGNALING
OUTPUT OR ACCESS
CONTROL DEVICE
N.C. INPUT FROM
FACP OR ACCESS
CONTROL DEVICE
POWER ON
LED
MOM5 module shown with wet and/or dry normally
open trigger inputs (Non-Latching):
– DC INPUT +
TRIGGER
NC C NO NC C NO
LED
DRY OUTPUT POWER FAIL
– DC INPUT +
TRIGGER
NC C NO NC C NO
LED DRY OUTPUT POWER FAIL
DC VOLTAGE INPUT
FROM FACP SIGNALING
OUTPUT OR ACCESS
CONTROL DEVICE
EOL 2.2K
N.O. INPUT FROM
FACP OR ACCESS
CONTROL DEVICE
EOL 2.2K
POWER ON
LED
TO TRIGGER INPUT
OF NEXT MOM5
EOL 2.2K
POWER ON
LED
TO TRIGGER INPUT
OF NEXT MOM5
M Series Installation Guide
