Power Measurements

Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into your power source when determining
product load.
Note:
The following notes apply to the following tables.
Tx Pulse: The average peak current during an LTE connection.
Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
Inrush Charge: The input current during power up, or a reset.

MTSMC-MNG6 Power Draw

Note: This table has been split for readability.
Radio Protocol
3.3 Volts
GSM850
LTE Band 5
836.5Mhz
5.0 Volts
GSM850
LTE Band 5
836.5Mhz
Radio Protocol
3.3 Volts
GSM850
LTE Band 5
836.5Mhz
5.0 Volts
GSM850
LTE Band 5
836.5Mhz
Note:
®
SocketModem Cell Cat M1 MTSMC-MNG6 Device Guide
Sleep Mode PSM Mode
Current CFUN=5 (CPSMS)
(If Applicable)
(Amps)
N/A N/A
30 mA 22 mA
N/A N/A
23 mA 20 mA
(AVG) Measured TX Pulse (Avg)
Current at Max Amplitude
Power CurrentPeak
Current for LTE
271 mA 2.0 A
440 mA 1.10 A
318 mA 1.91 A
265 mA 968 mA
eDRX Mode eDRX Mode
w/CFUN=5
N/A N/A
31 mA 26 mA
N/A N/A
26 mA 22 mA
Total Inrush Total Inrush
Charge Measured Charge Duration
in Millicoulombs during Power Up
0.400 mC 2.65 mS
0.400 mC 2.65 mS
0.300 mC 2.98 mS
0.300 mC 2.98 mS
SPECIFICATIONS
Cellular
Connection Idle
(No Data) (Amps)
33 mA
30 mA
30 mA
28 mA
