PRODUCT OVERVIEW
Category
Certifications and Compliance
EMC Compliance
Radio Compliance
Safety Compliance
Network Compliance
Carrier

LED Descriptions

The top panel contains the following LEDs:
Power LED—The Power LED indicates that DC power is present.
Link LED—The Link LED indicated that it is registered on the network.
Signal LEDs—Three signal LEDs can display the signal strength level of the wireless connection.
LED Indicators
POWER Indicates presence of DC power when lit.
LINK
SIGNAL These LEDs display the strength of the cellular signal.
For more information on using GPIO to control the LEDs, refer to the AT Command Guide.

Power Measurements

Multi-Tech Systems, Inc. recommends incorporating a 10% buffer into your power source when determining
product load.
8
Description
FCC Part 15 Class B
FCC Part 22H, 24E, 27
UL 60950-1 2nd ED
cUL 60950-1 2nd ED
IEC 60950-1 2nd ED
PTCRB
AT&T and Verizon
Off : No power to unit.
On: Continuously lit Powered on.
Slow blink (-0.2Hz): Registered on network.
Note: The three PROGAMMABLE SIGNAL LEDs can be controlled as follows:
GPIO2: Controls the LED with a single bar above it.
GPIO3: Controls the LED with two bars above it.
GPIO4: Controls the LED with three bars above it.
®
MultiConnect microCell MTCM-LNA3 User Guide
