MTSMC-MNG6-U Power Draw
Note:
This table has been split for readability.
Radio Protocol
3.3 Volts
GSM850
LTE Band 5
836.5Mhz
5.0 Volts
GSM850
LTE Band 5
836.5Mhz
Radio Protocol
3.3 Volts
GSM850
LTE Band 5
836.5Mhz
5.0 Volts
GSM850
LTE Band 5
836.5Mhz
Note:
Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE
connection. The transmission burst duration for GSM850 can vary, depending on what transmission
scheme is being deployed (GPRS Class 8, Class 10, GSM, etc.).
Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
Inrush Charge: The total inrush charge at power on.
eDRX Mode Used: Average current will be lower if a longer eDRX Period time is used. An eDRX
Period time of 81.9 seconds was used , with a 20 second paging time
(AT#CEDRXS=2,4,"0101","0111"). Issue AT#CEDRXS? command to view network supplied parameters.
®
SocketModem
Cell Cat M1 MTSMC-MNG6 Device Guide
Sleep Mode
PSM Mode
Current CFUN=0
(CPSMS)
(If Applicable)
(Amps)
N/A
N/A
N/A
22 mA
N/A
N/A
N/A
18 mA
(AVG) Measured
TX Pulse (Avg)
Current (Amps) at
Amplitude
Max Power
Current (Amps)
Peak Current for
LTE
287 mA
2.5 A
432 mA
1.07 A
320 mA
1.83 A
289 mA
628 mA
eDRX Mode
eDRX Mode
w/CFUN=5
N/A
N/A
48 mA
N/A
N/A
N/A
37 mA
N/A
Total Inrush
Total Inrush
Charge Measured
Charge Duration
in Millicoulombs
during Power Up
(Inrush duration)
0.281 mC
2.86 mS
0.281 mC
2.86 mS
0.293 mC
2.46 mS
0.293 mC
2.46 mS
SPECIFICATIONS
Cellular
Connection Idle
(No Data) (Amps)
49 mA
50 mA
42 mA
39 mA
17
