PRODUCT OVERVIEW
Category
Certifications and Compliance
EMC Compliance
Radio Compliance
Safety Compliance

RS-232 9-Pin Female Connector

Pin Abbreviation
1 CD
2 RX
3 TX
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI

Power Measurements

Multi-Tech Systems, Inc. recommends incorporating a 10% buffer into your power source when determining
product load.

Serial Model: MTC-MNK1-B01 Power Draw

Radio Sleep mode
Protocol current,
connected to
wireless
9 Volts
LTE 836.5 12 mA
MHz
(Band 5)
10
Description
KC
KC
IEC 60950-1 2nd ED
Description
Carrier Detect
Receive
Transmit
Data Terminal Ready
Ground
Data Set Ready
Request to Send
Clear to Send
Ring Indicator
Cellular call Average
box measured
connection, no current at
data maximum
power
26 mA 105 mA
In/Out
O
O
I
I
--
O
I
O
O
Average TX Total inrush
pulse charge, in
amplitude
current
144 mA 0.762 mC
MultiConnect
Total inrush
charge
duration during
power-up
9.1 mS
®
Cell MTC-MNK1 User Guide
