CHAPTER 3 –SPECIFICATIONS

Pin 58

Note: Pin 58 may or may not be available on some SocketModems.
Pin 58 LED Mode
OFF
600 ms ON/600ms OFF
75 ms ON/75 ms OFF/75 ms ON
3 s OFF
Flashing or Blinking
ON

Pin Availability by Build

Pin and Function
J24 - Reset
J26 - GND
J33 - RTS
J34 - RXD
J35 - TXD
J36 - RI
J37 - DSR
J38 - CTS
J39 - DCD
J40 - DTR
J41 - GND
J58 - LED LINK
J61 - VCC
J63 - GND

Power Measurements

Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into your power source when
determining product load.
Note:
Protocol is 1xRTT US Cellular 800 and 1xRTT US PCS 1900.
11
Operating Status
Subscriber Carrier Mode is OFF or running in SLEEP or ALARM mode.
No PIN entered, network search in progress, ongoing user authentication, or
network login in progress.
One or more CDMA contexts activated. Indicates CDMA data transfer: When a
transfer is in progress, the LED goes on within 1 second after data packets were
exchanged. Flash duration is approximately 0.5 s.
Connected to remote party or parameter exchange while call is set up or
disconnected.
Serial only GP-IP
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x
x x
x x
SocketModem CDMA MTSMC-C2 Device Guide
