Power Measurements

Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into your power source when determining
product load.
Note:
The following notes apply to the following tables.
■ Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE
connection. The transmission burst duration for GSM850 can vary, depending on what transmission
scheme is being deployed (GPRS Class 8, Class 10, GSM, etc.).
■ Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
■
Inrush Charge: The input current during power up, or a reset.

MTSMC-LAT1 Power Draw

Radio Protocol Sleep Mode w/
Connection to Live
Network (Active SIM
Installed) (Amps)
3.3 Volts
WCDMA 0.0049
LTE 0.027
5 Volts
WCDMA 0.012
LTE 0.013

MTSMC-LAT1-U Power Draw

Radio Sleep Mode
Protocol Current
(Amps)
3.3 Volts
GPRS N/A
LTE N/A
5 Volts
GPRS N/A
LTE N/A
®
SocketModem Cell LTE MTSMC-Lxx Device Guide
Sleep Mode Current
(Amps)
0.021
0.033
0.012
0.020
Cellular (AVG) Measured
Connection Idle Current (Amps) at
(No Data) Max Power
(Amps)
0.056 0.750
0.048 0.909
0.032 0.293
0.029 0.560
Cellular Connection
Idle (No Data) (Amps)
0.026
0.034
0.018
0.019
TX Pulse (AVG)
Amplitude Current
(Amps) for GSM850 or
Peak Current for
HSDPA/LTE )
3.48
N/A
2
N/A
SPECIFICATIONS
(AVG) Measured
Current (Amps) at Max
Power
0.558
0.401
0.556
0.4000
Total Inrush
Charge Measured
in Millicoulomb
(mC)
2.65
N/A
3.64
N/A
