E-PART
Part #
Order Code
37
B08ZX02CP-E
38
AKUA01002
39
ELPA04003
40
ELKS03003
41
ELKS03006
42
ELKA15002
43
ELON09023
43.1
B07EC5012
44
ELSK01001
45
ELKS03001
46
ELKS03010
* variable: varies according to the situation of the double axis.
E-DRIVE ZX02-E ROBOT MECHANICAL UNIT ELECTRICAL PANEL
HINGE 299-1-2-1
LOCK 140-1-2-64-01
SOCKET BINDER SOLDERED TYPE 7 PIN FEMALE PANEL CONNEC-
TOR
SOCKET BINDER SCREW TYPE 4 PIN MALE PANEL TYPE CONNEC-
TOR
CABLE ENTRY PART
AXIS CONTROL CARD
PLATE OF AXIS CONTROL CARD
DRIVER DELTA 0,75 kW
SOCKET BINDER SCREW TYPE 4 PIN FEMALE PANEL TYPE CON-
NECTOR
SOCKET BINDER SOLDERED TYPE 7 PIN MALE PANEL CONNECTOR
Part Name
Qty
1
2
2
1
1
1
Mutable
Mutable
Mutable
1
1
53
