Electron E-ROBOT+3 Series User Manual page 38

C) Weight
Stroke Lenght [mm]
1200
1500
1800
2100
2400
2700
Horizontal Reciprocator
NOTE:
Reciprocator enclosing dimensions are given so that two single vertical axes fit in the same case.
11.3. Transport
11.3.1 Data concerning goods to be transported
The space requirements correspond to the size of the axes of motion plus the packaging.
11.3.2 Loading, transferring the load, unloading
At least one fork lift must be available.
12. Ordering
12.1 Ordering Reciprocator Systems
Systems
Vertical Axis
Reciprocator
System
E-DRIVE ZX02-E RECIPROCATOR SIGNAL
E-DRIVE ZX02-E RECIPROCATOR POWER
38
Reciprocator (kg)
154
163
173
183
193
202
1) For a single Reciprocator system;
Products
E-ROBOT+3 Z
E-DRIVE ZX02-E
CABLE
CABLE
Case (kg)
2 reciprocators with case-SET (kg)
225
240
255
270
285
300
aprx. 250 (with palette)
Types
1200 Stroke
1500 Stroke
1800 Stroke
2100 Stroke
2400 Stroke
2700 Stroke
N/A
10 MT
15 MT
20 MT
25 MT
10 MT
15 MT
20 MT
25 MT
533
566
601
636
671
704
Codes Qty
B07RG0301
B07RG0302
B07RG0303
1
B07RG0304
B07RG0305
B07RG0306
B08ZX02CM-E 1
B08ZX02SC-E10
B08ZX02SC-E15
B08ZX02SC-E20
1
B08ZX02SC-E25
B08ZX02PC-E10
B08ZX02PC-E15
B08ZX02PC-E20
1
B08ZX02PC-E25
