NOTE:
All errors, except E220V, refer to the axis number which is indicated on the left side of
the E-Drive control unit during operatinon. An Error Code, for instance, E1000 that has
been observed during operating in axis page-2 does not mean that there is an E1000 error
in all of the axises. It means that the controller defines an error E1000 for axis.
NOTE:
Main Page must be switched over to other active axis pages to observe the condition of
each axis.
9.Maintenance
DANGER:
Injuries can occur inside the protective fence due to the movement
of the reciprocator!
**In order to enter the inner area, the door interlocks must be released by the control unit. This
release signal may only be activated by technical personnel.

9.1. General information

WARNING:
Before maintenance work can be carried out on the reciprocator, it must be ensured that the
reciprocator cannot be turned on by third parties!
**The reciprocator has to be free of load and disconnected from mains!
The E-ROBOT+3 Z Reciprocator was designed to operate with a minimum of maintenance. The motor gear box is
self-lubricating and maintenancefree.
Regular maintenance and inspection of the reciprocator increases the working reliability and avoids damages,
repair downtimes etc.!

9.2. Maintenance schedule

NOTE:
The following maintenance schedule is based on operation of 8 hours per day.
9.2.1 Weekly
- Blow off the outside of the reciprocator with compressed air or clean it with a soft cloth from top to bottom
at least once a week.
9.2.2 Monthly
- Check the drive unit gearbox for oil loss
- Check the motor case in the reciprocator base for deposits of powder dust and if present, clean it
9.2.3 Every 6 months
- Check the drive unit gearbox for oil loss
- Check the motor case in the reciprocator base for deposits of powder dust and if present, clean it
NOTE:
The parts, which are to be replaced during maintenance work, are available as spare parts.
Please refer to the spare parts list too!
9.3. Drive unit
DANGER:
During assembly, cleaning, maintenance and commissioning when close to energized
components, an electrical shock can cause serious injury or death.
** All work must be carried out only by technical personnel and when no power is applied!
** The reciprocator has to be free of load!
The motor gear box is self-lubricating and maintenance-free.
Observe the contamination of the enclosure - strong contamination on the outside can increase the operating
temperature of the drive unit!
Therefore, clean the drive unit from time to time (with a vacuum cleaner etc.). Check the drive unit gearbox
monthly for oil loss. If the drive unit gearbox has to be changed for any reason, the complete unit has to be replaced!
WARNING:
For safety reasons, two people should always carry out the following maintenance work!
28
