3.Technical Data
The E-ROBOT+3 Z Reciprocator is available, depending on operational area, in six versions with different
standard stroke heights.
3.1.Technical Data
*Vertical Axis
E-ROBOT+3 Z
Height
Stroke lenght
Belt
Order Code
A05RD01200+3-X
Stroke Speed
Acceleration
Position detection
*Horizontal Axis
E-ROBOT+3 X
Stroke lenght
Product Code
Stroke Speed
Position
Position detection
*Control Unit
E-DRIVE ZX02-E
Height
Widht
Depth
Weight
Product Code

3.2.Electrical Data

Power supply
Tolerance
Frequency
Protection Type
Operating Temperature Range
Max. Protection Surface Temperature

3.3.Sound Pressure Level

Normal operation
The sound pressure level was measured while the unit was in operation; measurements were taken at the most frequent oper-
ator positions and at a height of 1.7 m from the ground. The specified value is applicable only for this product itself and does
not take into account external noise sources or cleaning impulses. The sound pressure level may vary, depending on the product
configuration and space constraints.
12
1200
1500
2,524 m
2,824 m
1,2 m
1,5 m
4,7 m
5,3 m
A05RD01500+3-X
0.1 up to 0.6 m/s (6.0 up to 36.0 m/min.)
1000 mm
A05X031000
E-ROBOT+3 Z-Axis Reciprocator
E-ROBOT+3 Z-Axis Reciprocator
1800 2100
3,124 m 3,424 m
1,8 m 2,1 m
5,9 m 6,5 m
A05RD01800+3-X A05RD02100+3-X
0.5-2.5 m/s²
with incremental pulse generator
Technical Values
0.06 up to 0.15 m/s (4.0 up to 8.0 m/min.)
Zero point selectable in both end positions
with incremental pulse generator
182 mm
220 mm
250 mm
3.34 kg
B08ZX02CM-E
2400
3,724 m 4,024 m
2,4 m
7.1 m
A05RD02400+3-X A05RD02700+3-X
1500 mm
A05X031500
230 VAC (from control unit)
± 10%
50/60 Hz
IP54
-10°C - +40°C
135°C
< 60 dB(A)
2700
2,7 m
7.7 m
