7.E-DRIVE ZX02-E Reciprocator Control Unit and Setting
7.1.
Front Panel and Input Buttons
Display No
B1
B2
B3
B4
B5,B6,B7,B8,B9
K10
B11
B12
B13
B14
22
Display Name
Main Switch (ON-OFF)
Up Key
Down Key
Adjustment Led
Segment Buttons
Rotary Adjustment Knob
Reset Button
Axis Start/Stop Button
Menu Button
Axes Active/Passive Button
