Electron E-ROBOT+3 Series User Manual page 46

Part # Order Code
18 ELSN02008
19 B06RB01035
20 B06RB03088
21 TRTM06005
22 TRTM06029
23 BECV06001
24 B06RB03085
25 B07RBM132
25.1 TRTM06008
25.2 BECV06019
25.3 BEPL03006
25.4 BESM01007
25.5 TRTM08015
26 AKUA03020
27 BECV06021
28 BESM01007
46
SENSOR INDUCTIVE ATEX NBB8-18GM50-E2-3G-3D PEPPERL FUCHS
E-ROBOT SENSOR BASE
E-ROBOT V3 ROBOT SENSOR BASE COUNTERPART
E-ROBOT+3 STOPPER WEDGE BASE 25X20X128
STOPPER WEDGE BASE LOWER PART Ø35X15
COATED BOLT M5X10
E-ROBOT V3 BELT CONNECTION PLATE COUNTERPART
E-ROBOT LARGE WHEELSET - COMPLETE
LATHE E-ROBOT+3 WHEEL DISTANCE BUSH Ø16XL9,4
COATED BOLT M10X120
M10 DISTANCE RING-THIN(2mm)
M10 NUT
CARRIAGE ROLLER -Ø60 X L70
VIBRATION WEDGE M8X27 30x36 K TYPE
COATED BOLTM10X150
M10 NUT
Part Name Qty
1
1
1
1
1
1
2
8
1
1
1
1
1
1
2
2
