ISOMETER® isoCHA425HV + AGH420-1/AGH421-1
Abmessungen
Maßangabe in mm
Montage
1.
Montage auf Hutschiene | DIN rail mounting
4
isoCHA425HV_D00404_05_Q_DEEN / 11.2023
36
93
90
2.
3.
Click!
Dimensions
45 70,5
31,1
47,5
74,5
Dimensions in mm
Mounting
&
1 x
2 x
!
Schraubbefestigung | Screw mounting
Click
M4
M4
