Technical Specifications; Accessories Kit; Main Cable - Autel MaxiSys MS908CV II Manual

2.2.3 Technical Specifications

Item
Communications
Wireless Frequency
Input Voltage Range
Supply Current
Operating Temp.
Storage Temp.
Dimensions
(L x W x H)
Weight

2.3 Accessories Kit

2.3.1 Main Cable

The MaxiFlash Elite device can be powered through the Autel main cable when
connected to an OBDII/EOBD compliant vehicle. The main cable connects the MaxiFlash
Elite device to the vehicle's DLC, through which the MaxiFlash Elite device can transmit
vehicle data to the tablet.
Table 2-2 MaxiSys Elite Specifications
Description
Wireless BT V2.1 + EDR
⚫
USB 2.0
⚫
Wireless BT V2.1 +EDR, 2.4 GHz
12 V DC to 24 V DC
170 mA @ 12 V DC
100 mA @ 24 V DC
0 °C to 60 °C (32 °F to 140 °F) (ambient)
-20 °C to 70 °C (-4 °F to 158 °F) (ambient)
149 mm (5.87") x 86 mm (3.38") x 35 mm (1.28")
0.29 kg (0.64 lbs.)
Figure 2-5 Main Cable (1.5 m in Length)
9
