17.1 MaxiBAS BT506 Battery Tester
17.1.1 Function Description
Power Button
1.
Status LED
2.
Power LED
3.
USB Port
4.
Battery Clamp Cable
5.
LED
Status LED
Figure 17-2 MaxiBAS BT506 Tester
Table 17-1 LED Description
Color
Flashing Green
Flashing Blue
Flashing Red
Description
The tester is communicating via USB
cable.
The
tester
is
Bluetooth.
Battery clamps are connected to the
wrong battery terminals.
96
communicating
via
