1.3

Power Supply

The RG-PF2920-DPBOX-P uses DC input. The rated values are as follows:
Rated voltage range: 44 V DC to 57 V DC
Rated current: 0.75 A
1.4

Heat Dissipation

The RG-PF2920-DPBOX-P adopts natural heat dissipation to ensure that it works properly in a specified
environment. For the RG-PF2920-DPBOX-P, maintain sufficient clearance on both sides of the chassis and
above the chassis for air circulation. Dust the device every three months to avoid blocking ventilation openings
on the housing.
1.5 LEDs
LED
Status LED
Ethernet
electrical port
LED
Ethernet
electrical port
PoE LED
SFP port
LED
Panel
Status
Identification
Off
PWR
Solid green
Off
Solid green
LAN
Blinking green
Off
POE
Solid green
Off
Solid green
SFP
Blinking green
Description
The switch is not powered on.
The power supply is normal.
The port is not connected.
The port works at the rate of
10/100/1000 Mbps.
The port is sending or receiving
data at the rate of 10/100/1000
Mbps.
PoE of the port is disabled.
PoE of the port is enabled.
The port is not connected.
The port is connected.
The port is sending or receiving
data.
