Product Description - Ruijie RG-PF2920-DPBOX-P Series Hardware Installation And Reference Manual

Hardware Installation and Reference Guide
1

Product Description

The RG-PF2920-DPBOX-P is the simplified optical Ethernet (SOE) switch released by Ruijie Networks for all-
optical network scenarios. The switch connects to the uplink hybrid cable and provides downlink 1000M Ethernet
port, and supports PoE for external power supply.
Table 1-1 Configuration of the RG-PF2920-DPBOX-P
Model
RG-
PF2920-
DPBOX-
P
Note
1000Base-T is downward compatible with 100Base-T.
1.2 RG-PF2920-DPBOX-P
Table 1-2 Technical Specifications of the RG-PF2920-DPBOX-P
Model
CPU
BOOTROM
Flash Memory
SDRAM
Supported Optical
Module
SFP Port
Power Supply
EEE
10/100/1000M
Base-T Ethernet
Electrical Port
1
RG-PF2920-DPBOX-P
Built-in CPU and single-core processor
N/A
N/A
N/A
1000base-X supported only
See Appendix B.
The supported optical module types may update without prior notification.
Please contact Ruijie Networks for any updates.
1000Base-X
Rated voltage range: 44 V DC to 57 V DC
Rated current: 0.75 A
Not supported
SFP Available
Port PoE Power
1 30 W
- 1 -
Product Description
Dimensions (W Cooling
x D x H)
120 mm x 40 Natural heat
mm x 28.7 mm dissipation for
(4.72 in. x 1.57 fanless design
in. x 1.13 in.)
