RG-PF2920-DPBOX-P Series
Switch
Hardware Installation and Reference Guide
Document version: V1.04
Date: 2023-08-03
Copyright © 2023 Ruijie Networks

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-PF2920-DPBOX-P Series and is the answer not in the manual?

Questions and answers

Related Manuals for Ruijie RG-PF2920-DPBOX-P Series

Summary of Contents for Ruijie RG-PF2920-DPBOX-P Series

  • Page 1 RG-PF2920-DPBOX-P Series Switch Hardware Installation and Reference Guide Document version: V1.04 Date: 2023-08-03 Copyright © 2023 Ruijie Networks...
  • Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder...
  • Page 3 Preface Intended Audience This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Technical Support  Ruijie Networks website: https://www.ruijienetworks.com/  Technical support website: https://ruijienetworks.com/support  Case portal: https://caseportal.ruijienetworks.com  Community: https://community.ruijienetworks.com ...

  • Page 4: Product Description

    Product Description Product Description The RG-PF2920-DPBOX-P is the simplified optical Ethernet (SOE) switch released by Ruijie Networks for all- optical network scenarios. The switch connects to the uplink hybrid cable and provides downlink 1000M Ethernet port, and supports PoE for external power supply.
  • Page 5 Hardware Installation and Reference Guide Product Description Maximum overall PoE output power: 30 W Ethernet electrical ports support PoE. Maximum Power With PoE load: 33 W Consumption Without PoE load: 3 W Operating Rack deployment: 0º C to 45º C (32° F to 113° F) at the altitude between 0 m Temperature to 1,800 m (0 ft.
  • Page 6 Hardware Installation and Reference Guide Product Description Product label information Nameplate format: Warning In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. 1.2.2 Product Appearance The front panel of the RG-PF2920-DPBOX-P is equipped with one 10/100/1000M Base-T Ethernet port and one SFP port.
  • Page 7 Hardware Installation and Reference Guide Product Description Figure 1-2 Appearance of the RG-PF2920-DPBOX-P - 4 -...
  • Page 8 Hardware Installation and Reference Guide Product Description Figure 1-3 Rear Panel of the RG-PF2920-DPBOX-P Note: 1. 10/100/1000Base-T Ethernet port with 6. Ethernet electrical port PoE LED auto-negotiation 7. SFP port LED 2. DC power port 3. SFP port 4. Power supply LED 5.

  • Page 9: Power Supply

    Hardware Installation and Reference Guide Product Description Power Supply The RG-PF2920-DPBOX-P uses DC input. The rated values are as follows: Rated voltage range: 44 V DC to 57 V DC Rated current: 0.75 A Heat Dissipation The RG-PF2920-DPBOX-P adopts natural heat dissipation to ensure that it works properly in a specified environment.

  • Page 10: Preparing For Installation

    Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions Warning  To avoid personal injury and device damage, carefully read the safety precautions before you install the RG-PF2920-DPBOX-P.  The following safety precautions may not cover all possible dangers. 2.1.1 Mounting ...

  • Page 11: Installation Site Requirements

    Hardware Installation and Reference Guide Preparing for Installation 2.1.4 To prevent damage caused by static electricity, pay attention to the following points:  Keep the indoor installation environment clean and dust-free.  Keep the indoor humidity within a certain range. 2.1.5 Laser The RG-PF2920-DPBOX-P supports various types of optical transceivers available in the market, and these...
  • Page 12 Hardware Installation and Reference Guide Preparing for Installation performance and reliability of the switch while severely impacting its service life. Table 2-1 Ambient Temperature and Humidity Requirements of the RG-PF2920-DPBOX-P Operating Temperature Relative Humidity 0° C to 45° C (32° F to 113° F) (rack deployment) 10% to 90% RH (non-condensing) 0°...
  • Page 13 Hardware Installation and Reference Guide Preparing for Installation 2.2.4 Anti-interference The switch is susceptible to external interference by capacitive coupling, inductive coupling, electromagnetic waves, common impedance (ground) coupling, or conduction over power lines, signal lines, and output lines. Pay attention to the following points: ...

  • Page 14: Installing The Switch

    Hardware Installation and Reference Guide Installing the Switch Installing the Switch Caution  Before reading Chapter 3 Installing the Switch, ensure that you have read Chapter 2 Preparing for Installation carefully.  Verify that requirements described in Chapter 2 Preparing for Installation have been met. Installation Procedure Install the switch correctly Connect the power supply...

  • Page 15: Verifying The Installation

    Hardware Installation and Reference Guide Installing the Switch and keep the corresponding tail fiber connector clean. Installing the RG-PF2920-DPBOX-P Pay attention to the following points:  Connect the power cords of different colors to the corresponding cable terminals.  Ensure that the connector of the power cord is properly seated in the power port of the switch. After plugging the power cord into the switch, secure the power cord with power cord retention clip.

  • Page 16: Common Troubleshooting

    Check whether power cords are properly connected Check whether the LEDs are normal Check whether serial port is connected and whether parameters are set correctly Check whether port cables are connected correctly Contact Ruijie technical support Common Troubleshooting Fault Symptom Possible Cause Handling Method...
  • Page 17 Hardware Installation and Reference Guide Common Troubleshooting Rx and Tx ends are connected incorrectly. Connect the Rx and Tx ends of the optical The types of the interconnected fiber correctly. optical modules do not match. Replace optical modules with those of the An optical port cannot The optical fiber type does not same type.

  • Page 18: Appendix A Connectors And Media

    Hardware Installation and Reference Guide Appendix A Connectors and Media Appendix A Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T Port The 1000BASE-T/100BASE-TX/10BASE-T supports auto-negotiation of three rates and automatic MDI/MDIX crossover at these three rates. Conforming to IEEE 802.3ab, 1000BASE-T requires 100-ohm CAT5 or CAT5e, or higher 100-ohm UTP or STP (recommended) with a maximum distance of 100 m (328.08 ft.).
  • Page 19 Hardware Installation and Reference Guide Appendix A Connectors and Media Figure 5-2 100BASE-TX/10BASE-T Twisted Pair Connections Optical Cable Connections Select single-mode or multimode optical cables according to the module types. Figure 5-3 Optical Cable Connection - 16 -...

  • Page 20: Appendix B Optical Modules

    Appendix B Optical Modules Appendix B Optical Modules Ruijie provides supporting SFP modules (mini-GBIC modules) based on the port types of switch modules. You can select a module to suit your specific needs. This document provides models and technical specifications of some 1000M SFP modules for reference.
  • Page 21 Hardware Installation and Reference Guide Appendix B Optical Modules GE-SFP-LX20- –9 –3 –20 –3 1310TX/1550RX SM1310-BIDI GE-SFP-LX20- –9 –3 –20 –3 1550TX/1310RX SM1550-BIDI Table 6-2 SFP Module Cabling Specifications Core Size Connector Fiber Max. Cabling Model Type Type Distance (μm) 62.5/125 275 m MINI-GBIC-SX-MM850...
  • Page 22 Hardware Installation and Reference Guide Appendix B Optical Modules 50/125 550 m GE-SFP-LX 9/125 10 km Caution  An optical module is a laser transmitter. Do not look directly into the optical module to prevent it from burning your eyes. ...

  • Page 23: Appendix C Cabling

    Hardware Installation and Reference Guide Appendix C Cabling Appendix C Cabling When the RG-PF2920-DPBOX-P is installed against a wall, the following cable requirements must be met. Requirements for the Cable Bend Radius  The bend radius of a fixed power cord, network cable, or flat cable should be over five times greater than their respective diameters.

  • Page 24: Appendix D Equipment Room Site Selection

    Hardware Installation and Reference Guide Appendix D Equipment Room Site Selection Appendix D Equipment Room Site Selection  The equipment room should be at least 5 km (3.11 miles) away from heavy pollution sources, such as the smelter works, coal mines, and thermal power plants. The equipment room should be at least 3.7 km (2.30 miles) away from medium pollution sources, such as the chemical factory, rubber factory, and electroplating factory.
