b) Make sure the machine is securely installed to avoid tipping.
c) The safety zone area shifts accordingly when machine installed in tilt position. Please
increase the safety distance in the direction which machine tilt.
d) Check carefully the output nozzle of each machine, make sure the output nozzle is in good
shape and there is no powder aggregate.
®
2. Fill SPARKULAR
a) Open powder bags and fill the feeding hopper. Hopper capacity of SPARKULAR
500g.
b) Choose correct consumable according to the application scenario.
c) Please be noted that there may sparks or remains fall to the ground. Make sure no
flammable material on ground in the safety zone.
d) Maximum effect height: HC8200 LARGE
is 8m and HC8200 LARGE 7m.
e) Make sure the lid of hopper is locked tight after filling.
3. Connect Power / DMX cable
a) Connect a power cable to the POWER IN socket of SPARKULAR® Cyclone. Connect the other
end of power cable to the power source. Make sure power supply in consistent with the
rated voltage of the equipment, and the socket must well grounded.
b) If connect machine in sequence, please connect a power link cable to the POWER OUT of
previous machine, connect the other end of the power link cable to POWER IN of the next
machine.
c) The Maximum cascade of SPARKULAR
For 110V version SPARKULAR
directly. Do not connect exceed units to a single electrical circuit.
d) Power ON all SPARKULAR
Cyclone
is 10m, HC8200 LARGE
®
Cyclone is 2 units with one standard power cable.
®
Cyclone, we suggest each machine connect to power supply
®
Cyclone.
®
Cyclone is
is 9m, HC8200 LARGE
