NAV E 121 • Setup Guide (Continued)
Pairing devices via front panel
1. Use a small screwdriver to press and hold the encoder front panel ID button for approximately 3 seconds,
until the ID LED blinks. The encoder enters pairing mode, which allows decoders to receive the AV stream
from encoders.
2. One at a time, use small screwdriver to press and hold the decoder front panel ID button for approximately
3 seconds, until the ID LED blinks three times. The decoder is now paired to the encoder.
3.
Repeat step 2 for each decoder.
4. Use a Tweeker or other small screwdriver to press and release the encoder front panel ID button. The encoder exits pairing
mode.
5. Repeat steps 1 through 4 to pair decoders to other encoders.
After all devices are connected, powered on, and paired, the system is fully operational.
Operation in a System with a NAVigator
The Extron NAVigator is a system manager that easily configures and controls the NAV System. The NAVigator supports 16
endpoints by default, but a LinkLicense can upgrade its capabilities to support up to 240 endpoints. See the NAVigator User Guide,
available at www.extron.com

Connection Details

LockIt Lacing Brackets
®
1.
Plug the HDMI cable into the panel connection (see
2. Loosen the connection mounting screw from the panel enough to allow the LockIt lacing
bracket to be placed over it (
3. Place the LockIt lacing bracket on the screw and against the connector (
the screw to secure the bracket.
ATTENTION:
• Do not overtighten the connector mounting screw. The shield it fastens to is very thin
and can easily be stripped.
• Ne serrez pas trop la vis de montage du connecteur. Le blindage auquel elle est
attachée est très fin et peut facilement être dénudé.
4. Loosely place the included tie wrap around the connector and the LockIt lacing bracket as shown (
5. While holding the connector securely against the lacing bracket, use pliers to tighten the tie wrap, then remove any excess
length ( ).
5
NAV 1G PoE connector
Pins:
TIA/EIA T
12345678
568B
Pin Wire color
1 White-orange
Orange
2
3 White-green
4 Blue
5 White-blue
Green
6
7 White-brown
8 Brown
TP Wires
5
for details.
1
). The screw does not have to be removed.
2
Control connector
, at right).
), then tighten
3
Power connector
Smooth
SECTION A–A
3 3 3
1 1 1
3
4 4 4
5 5 5
).
4
Ridges
Captive
Screw
Connector
3"
16 (5 mm) MAX
A A
Power Supply
Output Cord
ID
NA NA N A N NAV E 121 A A
2 2 2
