Hardware Installation
Installing the
Installing
Device to a
Power Modules,
Check and
Preparations
Grounding
Specified
Cards, and
Confirmation
Position
Other Modules
Installing air filter modules:
For the S8610E, there are two types of air filter modules. One type of air filter modules are installed at the bottom of the
chassis (used for preventing dusts for line card and supervisor slots), as shown in the following figure on the left, and the
other type of air filter modules are installed inside the front fan panel (used for preventing dusts for FE card slots), as shown
in the following figure on the right.
