Hardware Installation
Installing the Device Installing Power
Check and
Preparations to a Specified Grounding Modules, Cards, and
Confirmation
Position Other Modules
The cabinet depth should be greater
than or equal to 1 m. The distance
between the column mounting bar of
the cabinet and the outer side of the
front cabinet door should be greater
than 180 mm and the thickness of the
front door should be smaller than 25
mm so as to ensure at least 155 mm
available space. In this way, after the
cable management bracket is installed
on the cabinet, the cabinet door can
be closed normally. For some
cabinets with the cabinet depth of 1
m, if the available distance between
the column mounting bar and the
cabinet door is smaller than 155 m,
the cabinet door cannot be closed and
the column mounting bar needs to be
moved backward.
