Rdbshnm 1 BGNNRHMF : KNB:SHNM ENQ XNTQ E:RSK:MD OQN
The Fastlane Pro can $t in virtually any swimming pool. For optimal water ;ow, we recommend that you
C
V
allow at least 12 feet (3,7m) between the wall on which the Fastlane Pro is installed and the opposing
wall in line with the Swim Unit. The Fastlane Pro has more than 9 square feet (.83m2) of water intake to
eliminate any entrapment hazards. The water depth where the Fastlane Pro is installed must be at least 39"
(99cm) deep. In addition, the Fastlane Pro must be installed no closer than 18" (46cm) from any adjacent
wall as shown in Figure 2.1, Minimum Clearance Guidelines.
When choosing a location for your Fastlane Pro, you should also consider the route for the hydraulic hoses
to run back to the Power Unit. The Power Unit needs to sit on a solid, level surface, preferably not on wet
ground, and requires a 30-amp, 220-volt GFCI electric service. For UK and international electrical require-
ments, please refer to Section 11. The optional Outdoor Power Unit with Weather Guard may be located
outside, but should not be subject to driving rain. Typically, the Power Unit is located with the other pool
equipment and, if possible, long hydraulic runs should be avoided because of pressure loss. If you wish to
have a run greater than 25' (7,6m), you must transition from 3/8" (9,5mm) hydraulic hoses to 1/2" (13mm)
run hoses with the addition of a junction box as reviewed in Section 5.
Ehf- 1-0 Lhmhltl BkdYqYmbd Fthcd
Rdbshnm 2 QDBDHUHMF XNTQ E:RSK:MD OQN
The Endless Pools Fastlane Pro arrives in a 49" x 41" x 37" (124cm x 104cm x 94cm) wooden crate.
C
V
Upon arrival, the crate should be inspected for external damage. Should there be visible damage, you
must complete a damage-claim report provided by the truck driver. Please call the Endless Pools shipping
department immediately at (800-732-8660.The Fastlane Pro shipment is comprised of the following.
Additional components may be included depending on the options ordered.
(1) Fastlane Pro Housing Assembly
(1) Hydraulic Power Unit
(1) Hydraulic Fluid (5 Gallon container)
(1) Accessory Kit for Fastlane Pro
V
Wall Mount Fastlane Pro
(1) Wall Mount Fastlane Pro Mounting Kit
C
Deck Mount Fastlane Pro
(1) Bracket Kit for Deck Mount Fastlane Pro
EYrskYmd Oqn Rvhl Tmhs HmrsYkkYshnm
°
