Rdbshnm 5
:RRDLAKX NE SGD E:RSK:MD OQN RVHL TMHS
6.1 Place the swim unit on a protective surface for the assembly. The components and hardware required
C
V
for the assembly are located in the Accessory Kit. When assembling the swim unit, a low torque set-
ting should be used on the drill to prevent the holes in the acrylic from stripping. Take care when
handling or working around any of the stainless steel components as the ends can be sharp.
6.2 Slide the vertical water-conditioning grill up and out of the housing assembly (Fig. 6.1).
UdqshbZk Fqhkk
Ehf- 5-0
6.3 Position the grab bar on the swim unit housing. Align the holes in the ;anges o2 the grab bar with the
corresponding holes on each side of the unit. Machine screws and nuts are used to secure the grab bar.
On the left side of the unit, there is pre-attached #8 Solid Insulated Copper Wire (Bonding Wire). Attach
wire to one of the screws before installing the nut. THIS STEP IS CRITICAL.
I6 the Fastlane Pro is being installed into a pool using a salt-chlorine generator, a sacri-cial zinc
anode MUST be installed to combat the corrosive nature of the salt. Secure anode to one of the grab
bar screws on the right side of the unit. DO NOT INSTALL ANODE UNLESS NEEDED (Fig. 6.2).
Ehf- 5-1
"6 Rnkhc HmrtkZsdc
Bnoodq Vhqd #Anmchmf(
FqZa AZq
EYrskYmd
Oqn Rvhl Tmhs HmrsYkkYshnm
°
Mts
w2
LZbghmd
Rbqdv w2
Whmb =mncd
17
