Rdbshnm 8 CDBJ LNTMS E:RSK:MD OQN HMRS:KK:SHNM
9.1 Loosely secure the hanger bracket to the hose cover tray with one of the provided 1/2" (13mm) screws.
C
Measure down from the top of the hanger bracket to the water line to capture the freeboard
measurement. Once the measurement has been taken, remove the hanger bracket (Fig. 9.1).
Bnohmf
Ehf- 8-0
9.2 Carefully lay the Fastlane Pro down on its front face. There are six pre-drilled holes in the center of the
housing assembly between the hat sections. Align the top set of holes with the appropriate number hole
in the hanger bracket (if the freeboard is 5" (12,7cm) then align the #5 holes with the top holes in the
housing). When the hanger bracket is positioned on the housing, use the provided 3/4" (19mm) screws
to attach (Fig. 9.2).
2.3 #/8ll( Oghkkhor
Sqtrr GdZc Rbqdv w5
Ehf- 8-1
VZsdqkhmd
GZmfhmf AqZbids
GZmfhmf AqZbids
Sgd mtladqr dsbgdc hm
aqZbids dptZk eqddanZqc
gdhfgs hm hmbgdr
EYrskYmd Oqn Rvhl Tmhs HmrsYkkYshnm
°
21
