Endless Pools FASTLANE PRO Owner's Manual page 46

EYrskYmd Oqn Rvhl Tmhs HmrsYkkYshnm
°
Rdbshnm 07 RTBSHNM NTSKDS EHSSHMF :RRDLAKX RDQUHBD HMRSQTBSHNMR
C
V
RTBSHNM NTSKDS EHSSHMF :RRDLAKX HMENQL:SHNM
RTBSHNM NTSKDS EHSSHMF :RRDLAKX QDOK:BDLDMS HMRSQTBSHNMR
Service Access: The use of adhesives or other attachment methods that prevent access to suction piping or SOFA components
requiring periodic servicing is prohibited.
The SOFA shall be replaced at or be6ore the end o6 the 25 year service li6e. The SOFA and fasteners securing the SOFA
should be inspected before each use throughout its service life. The SOFA MUST be repaired or replaced if it's missing,
loose, dented, cracked, or broken. The fasteners and corresponding receptacles MUST be replaced or repaired if damaged.
When service is required to replace the SOFA, it shall be done so with replacement fasteners provided by the manufacturer.
The fasteners securing the SOFA are #10 x 1" (25mm) 316 Stainless Steel Phillips Flat Head Machine Screws. The fasten-
ers MUST be installed using a #2 Phillips head screwdriver. The recommended torque for the fasteners is 25 inch-pounds.
DO NOT USE POWER TOOLS TO INSTALL FASTENERS. Start installation of the fastener by hand to ensure proper
thread engagement and to prevent cross threading.
1. Remove the top lid of the housing by removing the screws. If replacing the SOFA on a Deck Mounted unit, remove the
deck plate cover.
2. Remove the #8 solid copper insulated wires (bonding wires). For Wall Mounted units these wires are attached the
mounting rods. For Deck Mounted units, these wires are attached to the deck plate bottom.
3. Disconnect the hydraulic hoses outside the pool and then remove the Fastlane Pro from the pool.
4. Remove the hat sections from the back of the housing assembly.
5. Remove the outer arcs and discs from each side of the SOFA.
6. Remove the housing assembly from the base assembly by removing the screws on each side.
7. Remove the SOFA (with pre-attached bonding wires) from the base assembly by removing the nuts from the underside
of the motor plate and removing the 1" (25mm) Phillips Flat Head Machine Screws.
8. Replace the SOFA and ALL fasteners securing the SOFA following steps 1-7 in reverse order.
I6 ANY SOFA 6astener receptacle (screw hole) is damaged (stripped), it MUST be replaced with a new
receptacle following the instructions below:
8.1 Mark hole 1/2" (13mm) away from damaged receptacle.
8.2 Drill hole in the SOFA using 1/4" (6mm) drill bit.
8.3 Drill hole in PVC motor plate assembly using 11/64" (4mm) drill bit.
8.4 Use fasteners provided by the manufacturer to reinstall the SOFA.
34
