Endless Pools FASTLANE PRO Owner's Manual page 8

EYrskYmd Oqn Rvhl Tmhs HmrsYkkYshnm
°
Rdbshnm 0 FDMDQ:K NUDQUHDV NE E:RSK:MD OQN
The Fastlane Pro swimming machine by Endless Pools is a hydraulically-powered system that creates a
smooth, adjustable-speed swim current in a conventional pool. The Fastlane Pro has been fabricated with
the $nest, most durable materials and designed to meet the most stringent sa2ety standards including VGB
2017. The swim current produced is wider than your body and deeper than your stroke — far superior to
currents created by one or more jets. Two 3/8" (9,5mm) hydraulic hoses carrying a non-food grade,
biodegradable vegetable oil run between the Hydraulic Power Unit and the Fastlane Pro Swim Unit, thus
eliminating the need 2or electricity poolside. When pumped at high pressure, this hydraulic ;uid creates a
swim current by turning the shaft of a submerged stainless steel hydraulic motor in the Fastlane Pro Swim
Unit, which in turn rotates a 16" (40,6cm) diameter propeller. The Power Unit is activated using a 3-button
radio 2requency wireless transmitter that can turn the unit on and of and adjust the speed. It is best i2 the
Power Unit is within 25' (7,6m) of the Swim Unit to minimize pressure loss. An optional 6" (15,2cm) LED
Swim Pace Display is available to monitor the speed of the swim current.
Note: All of the 316L stainless steel screws provided for the assembly of this unit should be tightened to
The Fastlane Pro can be mounted one of two ways:
The Wall Mount Fastlane Pro fastens to the wall of the pool using the bracket provided. Two 1-1/2"
V
(38mm) PVC pipes which serve as conduits for the hydraulic hoses run under the pool deck to a remotely
located Hydraulic Power Unit, as shown in Figure 1.1.
Ehf- 0-0
The Deck Mount Fastlane Pro fastens to the pool deck using a Deck Plate and Hanging Bracket. The two
C
hydraulic lines then run back to the remotely located Hydraulic Power Unit. The hydraulic hoses can
be run through a conduit or run aboveground, as shown in Figure 1.2.
Ehf- 0-1
6
the recommended 25 in-lbs of torque.
V
: VZkk Lntms EZrskZmd Opn
C
: Cdbi Lntms EZrskZmd Opn
