12.1 Turn the circuit breaker 2or the Power Unit of. The next step is connecting the hydraulic hoses. I2 the
C
V
hoses attached to the Fastlane Pro are to be directly connected to the Power Unit, then adapters must
be attached to the ends of the hoses. These adapters are provided in the hardware kit. If additional run
hoses are being used, they will connect directly to the Power Unit without the use of adapters. The
low-pressure hose (attached to the Fastlane Pro) will have red tape wrapped around the hydraulic
$tting and will connect to the port on the $ll cap. The high-pressure hose will connect to the port on
the high-pressure manifold (Fig. 12.1).
12.2 Remove the antenna and transmitters from the inside of the Power Unit Controller. Thread the
antenna onto the antenna connection on the left side on the controller (Fig. 12.1).
Ehf- 01-0
12.3 Unthread the $ll cap and remove the oil $lter by pulling up on the tabs at the top and li2ting it out o2
the opening o2 the $ll cap assembly. Fill the Power Unit with approximately (4) gallons (15L) o2 the
hydraulic ;uid provided with the Fastlane Pro shipment. Once $lled with hydraulic ;uid, reinstall the
oil $lter and $ll cap.
12.4 Turn on the unit by pressing and holding the ON/OFF button (button in the center of the wireless
transmitter). If there is no swim current created in the pool after the unit has been running for
one minute, increase the speed by pressing and holding the 6aster button (up arrow) until a
current is produced.
12.5 Once the Fastlane Pro is 2ully installed and operational, turn the system of and disconnect the
low-pressure hydraulic hose (hose attached to $ll cap). Place the hose end into the 5-gallon (19L)
bucket used to $ll the power unit.
12.6 Turn on the Fastlane Pro, making sure to hold the hose $rmly in your hand over the bucket. The
returning hydraulic ;uid will ;ow into the bucket. The system will automatically shut of when the
;oat level switch inside the ;uid reservoir is tripped.
12.7 TURN THE CIRCUIT BREAKER FOR THE POWER UNIT OFF.
12.8 Reconnect the low-pressure hydraulic hose to the power unit and tighten. Remove the $ll cap and then
add 2 cups (480ml) o2 hydraulic ;uid. Reinstall the $ll cap and tighten.
12.9 Restore power to the equipment and test the unit. The system should stay on continuously. If the
system shuts of, even intermittently, shut power of at the circuit breaker and add an additional cup
(240ml) o2 hydraulic ;uid. Restore power to the equipment and turn the unit on to test.
