Module Programming - Directed DIRECTECHS DB3 Installation Manual

Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Wait until the LED turns ON solid red.
Note: To skip the transponder programming and use convenience features only, press the
1
programming button 5 times. Wait until the LED turns ON solid orange, then proceed with
step 2.
Important! Do NOT depress the brake pedal.
Press the Push-to-Start (PTS) button once to turn the ignition ON. The LED turns ON solid
2
green for 3 seconds, then shuts OFF.
If the transponder programming was skipped, the LED turns ON solid orange for 3 seconds
then shuts OFF when programming is done.
Press the PTS button once more to turn the ignition OFF, once the module is successfully
3
programmed.
You have successfully completed the module programming sequence.
9
403.NISS06 3.27 2016 Nissan Rogue (Smart Key)
